2380 LED highbay luminaire – the optimum solution for high rooms

2380 LED

LED highbay luminaires

Sensor accessories
IP65
Lens technology

The 2380 LED is a highbay luminaire for trade fair and exhibition halls, production facilities and warehouses. With IP65 it is also suitable for damp rooms and is available in three lumen packages. Single-point suspension means the luminaire is a simple 1:1 refurbishment solution. Optionally with sensor for particularly efficient lighting. This will get the job done!

Why you’ll get the job done with the 2380 LED highbay luminaire

Simple mounting thanks to single-point suspension small size and light aluminium housing
Suspension kit available as an accessory
1:1 replacement of conventional luminaires offering time and cost savings during refurbishment.
HF motion sensor available as accessory, ZHAGA interface
Efficient illumination of high halls thanks to lens optic with narrow-wide light distribution
Service life 50,000 h (L65)

2380 LED at a glance

Dimensions:
Ø 268 x 145 mm, Ø 310 x 145 mm

Luminaire luminous flux:
10,000 lm, 20,000 lm, 30,000 lm

Colour temperature:
4,000 K

Connected load:
77 W, 150 W, 200 W

Protection rating, Safety class:
IP65 / IK08 / I

Weight:
1,8 kg, 2,2 kg, 2,8 kg

Downloads

Series data sheet Installation instructions 2380 HF Installation instructions

Assembly video

All versions of 2380 LED

Product reference	TOC	Luminous flux [lm]	Wattage [W]	Light colour [K]	Dimensions LxWxH [mm]	Replacement	Data sheet
2380 G3 TB 10000-840 ET	7959440	10.000	77	4000	Ø 268 x 145 mm	150 W HQI / HSE	Download
2380 G3 TB 20000-840 ET	7959240	20.000	150	4000	Ø 310 x 145 mm	250 W / 400 W HQL 250 W HQI / HSE	Download
2380 G3 TB 30000-840 ET	7959340	30.000	200	4000	Ø 310 x 145 mm	400 W HQI / HSE	Download
